Key Specifications
Model Number
C4EST10.10CD
Height
1058mm
Width
966mm
Length
792mm
Weight
139kg
Product Features
- Direct steam system
- ACS+ (Advanced Closed System +) operating
modes: Steam, Combi-steam, Convection - ACS+ Extra Functions:
- Crisp&Tasty – 5 moisture-removal settings
- BakePro – 5 levels of traditional baking
- HumidityPro – 5 humidity settings
- Controllable fan – 5 speed settings
- easyTouch 9″ full-touch screen
- ConvoClean+ fully automated cleaning system with
eco, express and regular modes, including optional
single-measure dispensing - Ethernet / LAN interface
- HygienicCare
- USB port integrated in the control panel
- Steam generated by injecting water into the
cooking chamber - Right-hinged appliance door
- Disappearing door
Standard Features
- ACS+ operating modes:
- Steam (30-130°C) with guaranteed steam saturation
- Combi-steam (30-250°C) with automatic humidity adjustment
- Convection (30-250°C) with optimised heat transfer
- HygienicCare: safety through antibacterial surfaces
- easyTouch control panel
- Door handle and recoil hand shower
- easyTouch user interface:
- Full 9” full-touch screen
- Press&Go – automatic cooking using quick-select buttons
- TrayTimer – load management for different products at the same time
- Regenerate+ – versatile regenerating function with preselect
- ecoCooking – energy-save function
- Low-temperature cooking / Delta-T cooking
- Cook&Hold – cooking and holding in one process
- 399 cooking profiles containing up to 20 steps
- On-screen Help with topic-based video function
- Starting time preselect
- Multi-point core temperature sensor
- Door handle with safety latch and sure-shut function
- RS232 and RS485 interface
- Data storage for HACCP figures
- Preheat and Cool down function
Options
- Steam and vapour removal (built-in condensation hood)
- Grill model with grease collection
- ConvoSmoker smoker model
- Marine model
- Available in various voltages
- Sous-vide sensor, with external socket
- Core temperature sensor, with external socket
Electrical Connections
Power Rating
3N~ 400V 50/60Hz (3/N/PE), 28.1A, 19.5kW
Warranty
This unit comes with 12 Months warranty
Delivery & Freight
This product weights more than 30kg so it will require a forklift on site, or be delivered with a tail lift service. Please confirm your requirements for delivery of this prior prior to purchase. If you require the unit to be delivered into position so we can make this arrangment for you.
Curious to know how much freight will cost? get a quick freight quote!Finance
- ✔ Upgrade or purchase equipment at any time
- ✔ Return after 12 months if no longer needed
- ✔ Work towards ownership with Easy Own - enjoy a 30% discount on your weekly payments over 36 months
Made in Germany, the Convotherm range of combi-steamer ovens has been designed to enable and inspire better food preparation.
